Angry Miao Relic 80 Keyboard Shortcuts
Angry Miao Relic 80 Bluetooth
Pair Device 1: Fn + 1 (hold 3s) — Enter Bluetooth pairing mode for device slot 1. The 1 key lights up white continuously while pairing (other in-switch LEDs are disabled).
Pair Device 2: Fn + 2 (hold 3s) — Enter Bluetooth pairing mode for device slot 2. The 2 key lights up white continuously while pairing.
Pair Device 3: Fn + 3 (hold 3s) — Enter Bluetooth pairing mode for device slot 3. The 3 key lights up white continuously while pairing.
Switch Bluetooth Device: Fn + 1/2/3 — Short press to switch between previously paired Bluetooth devices 1/2/3.
2.4G Wireless Connection: Fn + 4 (hold 3s) — Establish a 2.4G wireless connection using the AM Sniper2.4 dongle. The 4 key lights up white continuously while connecting.
Angry Miao Relic 80 Lighting
Toggle In-Switch LEDs: Fn + F9 — Enable or disable the in-switch RGB LED backlighting.
Toggle Case Lighting: Fn + F10 — Enable or disable the case RGB underglow lighting.
Cycle In-Switch LED Effects: Fn + F11 — Cycle through available in-switch RGB lighting effects.
Cycle Case Lighting Effects: Fn + F12 — Cycle through available case RGB underglow lighting effects.
Increase Case Brightness: Fn + Up — Increase the brightness of the case RGB underglow lighting.
Decrease Case Brightness: Fn + Down — Decrease the brightness of the case RGB underglow lighting.
Increase Case Effect Speed: Fn + Right — Increase the animation speed of the case RGB lighting effect.
Decrease Case Effect Speed: Fn + Left — Decrease the animation speed of the case RGB lighting effect.
Increase In-Switch Brightness: Fn + = — Increase the brightness of the in-switch LED backlighting.
Decrease In-Switch Brightness: Fn + - — Decrease the brightness of the in-switch LED backlighting.
Angry Miao Relic 80 Media
Mute: Fn + F1 — Mute/unmute the system audio output.
Volume Down: Fn + F2 — Decrease the system volume.
Volume Up: Fn + F3 — Increase the system volume.
Previous Track: Fn + F4 — Skip to the previous media track.
Next Track: Fn + F5 — Skip to the next media track.
Play / Pause: Fn + F6 — Toggle media playback between play and pause.
Angry Miao Relic 80 Special
Power On/Off: Fn + Esc (long press) — Long press Fn+Esc to toggle the keyboard power on or off.
Factory Reset: Fn + R (hold 5s) — Restore keyboard to factory default settings. Hold for 5 seconds to confirm.
Auto Wired/Wireless Switch: Plug/unplug USB — The keyboard automatically switches between wired USB and Bluetooth/2.4G modes when the cable is plugged in or removed.
Key Remapping via DIY: diy.angrymiao.com — All keys support remapping and layer customization through the Angry Miao DIY web configurator. Download firmware updates from the same site.
